Detecting type: Catalytic combustion
Target gas: Alkanes and Combustible gases
Measuring Range: 3~100%LEL
Operating Voltage Range: DC24V±10V
Sampling: Diffusion
Power Consumption: ≤3W (DC24V)
Output; 1 Passive output, associated with High/low alarm.Normally on. closed on alarm.
Communication model: 4-Wire ABUS
Communication range: ≤1500m(1.5mm2)
Ex CERTIFICATION: Ex d ⅡC T6 Gb
IP Rating: IP66
Enclosure material: 304 Stainless steel .Tempered glass
Cable entries: G1/2 Internal screw thread
Display: A four digit 8-segment 2.1 inch bright LED for displaying the current status of the transmitter.
Operating: IR remote control ≤ 8m
Sensor’s expected Operating Life: 3 years（typical）
Low alarm: 25%LEL( factory setting )
High alarm: 50%LEL( factory setting )
Response time: <30s(T90)
Output range: ≤30V,2A( maximum limiting current )
Weight: 1.5Kg
Circuit: Over range protection
Temperature-Humidity Range: -40℃~+70℃，≤93%RH
Operating Pressure Range: 86kPa~106kPa
Dimension: 195mm×140mm×94mm
