Detecting type: Catalytic combustion
Detecting gas: Alkanes and combustible gas
Measuring range: 3~100%LEL
Operating voltage: DC24V±6V
Sampling: Diffusion
Power Consumption: ≤1.5W (DC24V)
Use: ASD5380 BUS：4BUS DO
ASD5380I：Three 4~20mA poitline
Output: 1 Passive output, associated with High/low alarm.Normally on . Alarm will get it closed.
Communication: 4BUS communication . 3 Distribution Line 4~20mA output
Communication range: ≤1500 m(1.5mm2)
EX certificate: Exd IIC T6 Gb
IP ratting: IP66
Enclosure: Aluminum alloy. Tempered glass
Cable entries: G3/4 Internal screw thread
Temperature-Humidity Range: -40℃~+70℃，≤93%RH
Operating Pressure Range: 86kPa~106kPa
Display: 2.1 inch LED.4 Bit Nixietube 8-Segment Numeric +Graphical display
Operating: IR remote control ≤ 8m
Sensor’s expected Operating Life: 3 years（typical）
Alarm accuracy: ±3%LEL
Display accuracy: ≤±5%LEL
Low alarm: 25%LEL(Factory setting)
High alarm: 50%LEL(Factory setting)
Response time: <30s(T90)
Output range: ≤30V，2A(maximum limiting current
Weight: 1.4Kg
Circuit: Overrange protection
Dimension: H205mm×L162mm×D80mm
